Shaft and wheel SW-G080
Shaft and wheel SW-G080

Shaft and wheel SW-G080

SW-G080
New
In Stock (24 Items)
€29.89
Tax included

434883-0015, SW-G080

Shaft and wheel SW-G080 for turbos 710415-0001, 710415-0003, 710415-0007, 723167-0001, 723167-0002, 723167-0003, 723167-0004.



SW-G080 - Shaft and wheel

Brand: Vortex

Vortex Reference: SW-G080

SW-G080 - Alternative numbers

GHO (Garrett original part number): 434883-0015

SW-G080 - Compatibility table

Shaft and wheel SW-G080 - Compatible turbochargers
TURBO MAKERTURBO MODELTURBO REFERENCETURBO OE NUMBER
GarrettGT2052V710415-000111657781434, 7780199D
GarrettGT2052V710415-000377814359
GarrettGTA2052V710415-000777814359
GarrettGT2052S723167-00018602480, 8603296, 8627752, 8653146
GarrettGT2052S723167-00028602480, 8603296, 8653146
GarrettGT2052S723167-00038602480, 8603296, 8653122
GarrettGT2052S723167-00048602480, 8603296, 8689592

SW-G080 - Part Properties

Blades (Shaft blades count): 9

Type (Shaft & Wheel Type): Straight

Inducer Diameter A (Inducer Diameter A): 47.0

Exducer Diameter B (Exducer Diameter B): 40.0

Tip Height C (Tip Height C): 8.5

Journal Bearing Diameter D (Journal Bearing Diameter D): 7.9

Compressor Wheel Diameter E (Compressor Wheel Diameter E): 5.1

Shaft Length (mm) (Shaft Length (mm)): 92.5

Back (Back): Open

Piston Ring Type (Piston Ring Type): Single

Model (Model): GT15-25

11657781434, 710415-0001, 7780199D, 710415-0003, 77814359, 710415-0007, 77814359, 723167-0001, 8602480, 8603296, 8627752, 8653146, 723167-0002, 8602480, 8603296, 8653146, 723167-0003, 8602480, 8603296, 8653122, 723167-0004, 8602480, 8603296, 8689592
